Item

Function

Test Conditions and Requirements

Rating Voltage

5V

12V

Operaing Voltage

4.5V—6V

10.8V—13.2V

No-Load Current

200mA

100mA

Load Current

430mA

150mA

Fill with 50KPa gas into 100CC bottle to test the working current of the product.

Air Flow

1.0L—2.0L

Pressure

＞80Kpa

Noise

55dB

55dB

Fill with 50Kpa gas into 100CC bottle to test the product's working noisy（Ambient noise ≤ 45dB）

Service Life

Carbon Brush

＞350H

Metal Brush

＞100H

Operating Enviroment

Temperature：5-50°C

Humidity：30-80%

Fluid Usage

Air

Weight

37.8g
